NAD 8 Channel Amplifier

Description

NAD CI980 | 8 Channel Amplifier

Continuous Output Power

• 8 Ohms: 8 x 50W (ref. rated THD, 20Hz-20Hz, all channels driven)
• 4 Ohms:8 x 60W
• 8 Ohms (Mono, Bridge Mode):120W
• Rated THD (250mW to rated power, CCIF IMD, DIM 100):<0.03% (ref. 20Hz-20kHz)
• Clipping Power:>155W (ref. 1kHz, 8 Ohms, 0.1% THD)
• Damping Factor:>150 (ref. 8 Ohms, 50Hz and 1kHz)
• Input Sensativity:1.1V (ref. rated power)
• Voltage Gain: 33dB
• Frequency Response: ±1dB (ref. 20Hz-20kHz)
• Signal/Noise Ratio, A-Weighted:>80dB (ref. 1W), >100dB (ref. 50W)
• Minimum Input Signal to trigger (auto sense mode):>20mV
• Time to Automatic Standby (without signal at input sense mode): 10 minutes

  GENERAL

• Rated Power: 600W (120V 60Hz, 230V 50Hz)
• Idle Power: <26W
• Standby Power: <0.5W
• Dimensions (W x H x D)*: 483 x 105 x 323mm (19 x 4 3/16 x 12 3/4”)**
• Net Weight: 5.72kg (12.6lb)
• Shipping Weight: 7.1kg (15.65lb)
